Suzhou Since Gas System Co.,Ltd
Provide reliable service&products for gas field,push industry civilization progress!
 |
| Place of Origin: | China |
| Brand Name: | JOSHINING |
| Certification: | CE, GB |
| Model Number: | JOHPS |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | $290000-$350000 |
| Packaging Details: | Packaging suitable for export transportation |
| Delivery Time: | 90days after payment |
| Supply Ability: | 50sets/year |
| Power: | 200kW | Output Voltage: | 415VAC |
|---|---|---|---|
| Power Source: | Hydrogen | Application: | Electric Generation |
| Size: | Containerized | Standard: | GB |
| Trade Term: | EXW，FOB | OEM: | Yes |
| Highlight: | 200kW Hydrogen Power Unit,200kW Hydrogen Stationary Power Plant,Electric Generator Hydrogen Power Plant |
||
200kW Hydrogen Stationary Power Plant for electric generation station
We have provided a 200kW system for overseas customers, utilizing the by-product hydrogen from the factory as a fuel source. This system is designed to replace the existing diesel backup generators in power plants.
| System rated power (kW) | 200kW |
| Output Voltage (V/AC) | 415VAC |
| Power Plant Efficiency | ＞39% |
| -30℃ Cold Start-up to Standby (mins) | ≤15min |
| Standby to Idle Power (seconds) | ≤30s@≥5℃ |
| Idle Power Output (kW) | ≤20kW |
| Hydrogen Purity | ≥99.97% Dry Hydrogen (CO<0.1ppm) |
| Hydrogen Inlet Pressure (Bar) | 11-13 Bar |
| Coolant |
Up to 50% pure ethylene glycol 50 % to 100% (deionized water); < 100 μm (particle size) |
| Communication Protocol | CAN2.0B/Modbus TCP |
| Operating Relative Humidity | 99% No Condensing |
| Installation Environment | Outdoors -30°C ~ +45°C |
