5-1000Nm3/H Ammonia Cracking Unit / Automatic Ammonia Gas Generator Simple Installation

Product Details:

Place of Origin:	Suzhou,China
Brand Name:	SINCE-GAS
Certification:	CE,ABS,CCS,BV,DNV,ASME,GOST,
Model Number:	ANH

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiate
Packaging Details:	Normal exported wooden case
Delivery Time:	2 months after received down payment
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	1000 sets/year

Contact Now

Detailed Product Description

Name:	Ammonia Cracking	Material:	Carbon Steel
Capacity:	5-1000Nm3/h	Feature:	Simple Installation
Supply Power:	380V/460V/415V/3P/50/60 Hz	Catalyst:	Nickel Catalyst
Cost:	Low Power Consumption	Dew Point:	-65C
Application:	Heat Treatment , Glass Floating, Steel Industry Etc
Highlight:	380V Ammonia Cracking Unit , 1000Nm3/H Ammonia Cracking Unit , Carbon Steel Ammonia Gas Generator

5-1000Nm3/H Ammonia Cracking / Automatic Ammonia Gas Generator Simple Installation

Ammonia Cracking Introduction

The ammonia cracking unit makes use of a nickel catalyst to crack or break ammonia into a mixture of

Hydrogen and nitrogen under an endothermic reaction. The raw material for ammonia crackers is ammonia gas

and this gas is easily available in cylinders. When ammonia is passed over the catalyst, the cracking

takes place at 8500 degrees C temperature and it cracks into an N2 + H2 mixture containing 75% hydrogen

and the remaining 25% is nitrogen. The cracked ammonia gas consists of approximately 80 PPM

uncracked ammonia impurities and its dew point is only 300 degrees C. There is a special tank surrounding the

cracker where the nitrogen and hydrogen are separated. Since hydrogen is 14 times lighter than nitrogen, it

rises to the top of the tank, while a special relief valve at the bottom of the tank allows the nitrogen at the base

of the tank.

Condition: New

Type: Resistance Furnace

Usage: Heat Treatment Furnace

Dimension(L*W*H): Various

Weight: 3-20ton

Warranty: 12 months

After-sales Service Provided:

Engineers available to service machinery overseas

Quality: Superior

Design: Novel

Price: Competitive

Rated heating power of purifier (kw): 2~10

Rated ammonia consumption (kg/h): 2~16

Catalyzer: Nickel catalyst

Product feature:
With a compact design and convenient installation, the core part of the cracking system is made of INCO ALLOYS, which is

material of corrosion-resistant, Alka-resistant, and Acid-resistant, service life is more than 10 years.
Heat preservation of the furnace is full fire structure, with the advantage of rapid temperature rise.
The heating element is made of full alloy, heating type is a plug fuse, there's no need to stop the gas when replacing

the heat elements. Alarm automatically when the pressure is too high or too low.

Above are standard fittings, The 50-1000Nm3/h ammonia decomposition generator is non-standard equipment, which can be provided according to demand. Fitting also can be upgraded according to requirement:
1. PLC programmed controller can be added, which can automatically control the conversion of various working states of the equipment.
2. Dew point detector can be added.
3. Gas content testing system can be added.

4. Characteristics

(1) Small investment

(2) Reliable performance and long service life

(3) Heating element

(4) Thermal insulation material

(5) Electrical control

(6) Depressurization system

(7) Purification system

(8) Simple installation

(9) Easy operation and maintenance

(10) High safety

Ammonia Cracker Model Specification

SN	Model	Nm/hr	V/Hz	kW
1	ANH-NHP-5-0.5/2	5	220/50	6+0.5
2	ANH-NHP-10-0.5/2	10	220/50	12+0.8
3	ANH-NHP-20-0.5/2	20	380/50	22+1.6
4	ANH-NHP-30-0.5/2	30	380/50	32+2
5	ANH-40-0.5/2	40	380/50	36
6	ANH-50-0.5/2	50	380/50	44
7	ANH-60-0.5/2	60	380/50	52
8	ANH-70-0.5/2	70	380/50	58
9	ANH-80-0.5/2	80	380/50	64
10	ANH-90-0.5/2	90	380/50	88
11	ANH-100-0.5/2	100	380/50	88
12	ANH-110-0.5/2	110	380/50	104
13	ANH-120-0.5/2	120	380/50	104
14	ANH-140-0.5/2	140	380/50	117
15	ANH-150-0.5/2	150	380/50	138
16	ANH-160-0.5/2	160	380/50	138
17	ANH-180-0.5/2	180	380/50	155
17	ANH-200-0.5/2	200	380/50	155
19	ANH-250-0.5	250	380/50	196
20	ANH-300-05	300	38050	242
